General Information ....................................................................... 24
Inspecting the Unit ......................................................................... 25
Installing the Unit ........................................................................... 26
Connecting the Line Cord .............................................................. 30
Connecting the Outputs ................................................................. 31
Remote Sense Connections ........................................................... 36
Parallel Connections ...................................................................... 38
Series Connections ......................................................................... 40
Additional Load Considerations ..................................................... 42
Connecting the Auxiliary Voltage Measurement Input ................. 44
This chapter describes how to install your power system. It discusses
rack mounting and line cord connections.
This chapter also discusses how to connect your load to the output
terminals. It discusses what you need to know about wire sizes and how
to compensate for voltage drops in the load leads. It describes various
loads configurations and how to connect the output terminals in series
and parallel.
Before installing the instrument, check the list under “Items Supplied”
and verify that you have received these items with your instrument. If
anything is missing, please contact your nearest Keysight Sales and
Support Office.
