1 Quick Reference
14 Keysight N6700 User’s Guide
Front Panel Menu Reference
NOTE
Menu commands that appear grayed-out on the front panel are either not
available for the power module, or are password protected.
Menu Command
Control Description
Output Voltage Programs voltage setting, limits, and ranges.
Current Programs current setting, limits, and ranges.
Mode Programs output priority mode on Models N678xA SMU.
Sequence Delay Programs Turn-on /Turn off delay.
Couple Couples output channels for output on/off synchronization.
Advanced Slew Voltage Programs voltage slew rate.
Current Programs current slew rate on Models N678xA SMU.
Power Programs the power allocation function.
Pol Lets you reverse the polarity of the output and sense terminals.
Resistance Programs output resistance on Models N6781A, N6785A.
Bandwidth Programs output voltage bandwidth on Models N678xA SMU.
Tmode Programs turn-on/turn-off impedance on Models N678xA SMU.
Measure Range Selects voltage and current measurement range.
Sweep Specifies measurement points, time interval, and trigger offset.
Window Selects measurement window: Rectangular, Hanning.
Input Selects Auxiliary voltage measurements on Models N6781A, N6785A.
Control Lets you abort a measurement in progress.
Transient Mode Selects voltage or current transient mode: Fixed, Step, List.
Step Programs voltage and current step value. Enables step triggers.
List Pace Specifies Dwell or Trigger paced list.
Repeat Specifies number of list repetitions, or specifies continuous list.
Terminate Specifies list settings when the list terminates.
Config Configures list step voltage, current, dwell, and trigger signals.
Reset Aborts the list and resets all list parameters.
TrigSource Specify the trigger source: Bus, Tran 1-4, Pin 1-7, Ext.
Control Initiates, Triggers, or Aborts output triggers. Displays trigger state.
Protect OVP Configures over-voltage protection function.
OCP Configures over-current protection function.
Inhibit Configures the external inhibit signal: Off, Latching, Live
Coupling Disables ALL output channels when a protection fault occurs.
Wdog Configures the output watchdog timer.
Osc Enables/disables oscillation protection on Models N678xA SMU.
Clear Clears output protection. Displays output state.
States Reset Resets the instrument to its reset (*RST) state.
SaveRecall Saves or recalls an instrument state.
PowerOn Selects the power-on state: *RST, RCL0.
