Menu Command
Control Description
System IO LAN ActiveSettings Displays the LAN interface settings that are presently active.
Config IP Configures the IP addressing of the instrument.
Name Configures the Dynamic DNS and NetBIOS naming service.
Domain Configures the Domain Name.
DNS Configures the DNS server.
TCP Configures the TCP keepalive function.
Reset Resets the LAN interface settings to the factory-shipped state.
USB Status Displays status, speed, packets received, and packets sent.
Identification USB connect string - the instrument’s unique USB identifier.
GPIB Selects the GPIB address.
DigPort Pins<1> Function Specifies the pin function: DigIn, DigIO, TrigIn, TrigOut, FaultOut.
Pins<2> Function Specifies the pin function: DigIn, DigIO, TrigIn, TrigOut.
Pins<3> Function Specifies the pin function: DigIn, DigIO, TrigIn, TrigOut, InhibitIn.
Pins<4-7> Function Specifies the pin function: DigIn, DigIO, TrigIn, TrigOut, OnC, OffC.
Pins<1-7> Polarity Specifies the pin polarity: Positive, Negative
Data Sends/reads data from the digital I/O port
Groups Defines groups of output channels that are connected in parallel.
Preferences Display Contrast Configures the display contrast.
Saver Configures the screen saver and wake-on I/O timer.
View Selects 1-channel or 4-channel view at turn-on
Keys Enables/disables key clicks and configures the On/Off key.
Lock Locks front panel keys. Enter a password to unlock the front panel.
Admin Login/Logout Enter a password to access the admin functions.
Cal Volt Vprog Calibrates High and Low voltage ranges.
Vlim Calibrates voltage limit High and Low ranges
Vmeas Calibrates High, Low, and Aux voltage measurement ranges.
Curr Iprog Calibrates High and Low current ranges.
Ilim Calibrates current limit.
Imeas Calibrates High and Low current measurement ranges.
Misc CMRR Calibrates common mode rejection ratio.
Dprog Calibrates the downprogrammer.
Ipeak Calibrates I peak.
Resistance Calibrates output resistance High and Low ranges.
Date Saves the calibration date for each channel.
Save Saves the calibration data.
LAN Enables/disables the LAN interface and the built-in Web server.
USB Enables/disables the USB interface.
Nvram Resets all non-volatile RAM settings to their factory defaults.
Password Changes the password for the admin functions.
About Frame Displays model, serial number, and firmware revisions.
Module Displays model, serial number, options, voltage, current, power.
