Appendix A Specifications
100 Keysight N6700 User’s Guide
Keysight N6700B, N6701A, N6702A MPS Mainframes
Supplemental Characteristics
N6700B, N6701A, N6702A
Maximum Power Available for Modules:
(sum of total module output power)
400 W (for N6700B mainframes)
600 W (for N6701A mainframes)
1200 W (for N6702A mainframes)
Internal Flash Memory:
8 Mbyte
Protection Response Characteristics:
INH input
Fault on coupled outputs
5 µs from receipt of inhibit to start of shutdown
< 10 µs from receipt of fault to start of shutdown
Command Processing Time:
≤ 1 ms from receipt of command to start of output change
Digital Control Characteristics:
Maximum voltage ratings
Pins 1 and 2 as FLT output
Pins 1 - 7 as digital/trigger outputs
(pin 8 = common)
Pins 1 - 7 as digital/trigger inputs
and pin 3 as INH input
(pin 8 = common)
+16.5 VDC/− 5 VDC between pins
(pin 8 is internally connected to chassis ground).
Maximum low-level output voltage = 0.5 V @ 4 mA
Maximum low-level sink current = 4 mA
Typical high-level leakage current = 1 mA @ 16.5 VDC
Maximum low-level output voltage = 0.5 V @ 4 mA;
1 V @ 50 mA; 1.75 V @ 100 mA
Maximum low-level sink current = 100 mA
Typical high-level leakage current = 0.8 mA @ 16.5 VDC
Maximum low-level input voltage = 0.8 V
Minimum high-level input voltage = 2 V
Typical low-level current = 2 mA @ 0 V (internal 2.2k pull-up)
Typical high-level leakage current = 0.12 mA @ 16.5 VDC
Interface Capabilities:
GPIB
LXI Compliance
USB 2.0
10/100 LAN
Built-in Web server
SCPI - 1993, IEEE 488.2 compliant interface
Class C (only applies to units with LXI label on front panel)
Requires Keysight IO Library version M.01.01 or 14.0 and up
Requires Keysight IO Library version L.01.01 or 14.0 and up
Requires Internet Explorer 7+ or Firefox 2+
Regulatory Compliance:
EMC
Safety
Complies with European EMC Directive for test and measurement
products.
● IEC/EN 61326-1
● CISPR 11, Group 1, class A
● AS/NZS CISPR 11
● ICES/NMB-001
Complies with Australian standard and carries C-Tick mark.
This ISM device complies with Canadian ICES-001.
Cet appareil ISM est conforme à la norme NMB-001 du Canada.
Complies with European Low Voltage Directive and carries the CE-
marking.
Conforms to UL 61010-1 and CSA C22.2 61010-1.
