Keysight Technologies N6700 User Manual

1 Quick Reference
18 Keysight N6700 User’s Guide
SCPI Command
Description
:PROTection
:CLEar (@chanlist)
Resets latched protection
:COUPle <Bool>
Enables/disables channel coupling for protection faults
:DELay <NRf+>, (@chanlist)
Sets over-current protection programming delay
:OSCillation <Bool>, (@chanlist)
Enables/disables output oscillation protection (N678xA SMU)
:WDOG
[:STATe] <Bool>
Enables/disables the I/O watchdog timer
:DELay <NRf+>
Sets the watchdog timer delay
:RELay
:POLarity NORMal | REVerse, (@chanlist)
Sets the output relay polarity (Option 760)
SENSe
:CURRent
:CCOMpensate <Bool>, (@chanlist)
Enables/disables the capacitive current compensation
[:DC]:RANGe
[:UPPer] <NRf+>, (@chanlist)
Selects the current measurement range
:AUTO <Bool>, (@chanlist)
Enables/disables measurement autoranging (N6781A, N6782A, N6785A,
:ELOG
N6786A)
:CURRent
[:DC]:RANGe
[:UPPer] <NRf+>, (@chanlist)
Sets the external data log current range
:AUTO <Bool>, (@chanlist)
Enables/disables measurement autoranging (N6781A, N6782A, N6785A,
N6786A)
:FUNCtion
:CURRent <Bool>, (@chanlist)
Enables/disables external current data logging
:MINMax <Bool>, (@chanlist)
Enables/disables external min/max current data logging
:VOLTage <Bool>, (@chanlist)
Enables/disables external voltage data logging
:MINMax <Bool>, (@chanlist)
Enables/disables external min/max voltage data logging
:PERiod <NR1>, (@chanlist)
Sets the integration time of the external data logging
:VOLTage
[:DC]:RANGe
[:UPPer] <NRf+>, (@chanlist)
Sets the external data log voltage range
:AUTO <Bool>, (@chanlist)
Enables/disables measurement autoranging (N6781A, N6782A)
:FUNCtion “VOLTage” | ”CURRent” | “NONE”, (@chanlist)
Selects the measurement function (for backward compatibility)
:CURRent <Bool>, (@chanlist)
Enables/disables current measurements (replaces FUNCtion)
:VOLTage <Bool>, (@chanlist)
Enables/disables voltage measurements (replaces FUNCtion)
:INPut MAIN | AUXiliary, (@chanlist)
Selects the voltage measurement input (only on N6781A, N6785A)
:SWEep
(Sweep commands only on N676xA, N678xA SMU and Option 054)
:OFFSet
:POINts <NRf+>, (@chanlist)
Defines the trigger offset in the measurement sweep
:POINts <NRf+>, (@chanlist)
Defines the number of data points in the measurement
:TINTerval <NRf+>, (@chanlist)
Sets the measurement sample interval
:RESolution RES20 | RES40, (@chanlist)
Sets the measurement resolution
:VOLTage
[:DC]:RANGe
[:UPPer] <NRf+>, (@chanlist)
Selects the voltage measurement range
:AUTO <Bool>, (@chanlist)
Enables/disables measurement autoranging (N6781A N6782A)
:WINDow
[:TYPE] HANNing | RECTangular, (@chanlist)
Selects measurement window (N676xA, N678xA SMU, Option 054)
[SOURce:]
CURRent
[:LEVel]
[:IMMediate][:AMPLitude] <NRf+>, (@chanlist)
Sets the output current
:TRIGgered [:AMPLitude] <NRf+>, (@chanlist)
Sets the triggered output current
:LIMit
[:POSitive]
[:IMMediate][:AMPLitude] <NRf+>, (@chanlist)
Sets the positive current limit (only on N678xA SMU, N6783A)
:COUPle <Bool>, (@chanlist)
Sets the current limit tracking state (only on N678xA SMU)
:NEGative
[:IMMediate][:AMPLitude] <NRf+>, (@chanlist)
Sets the negative current limit (only on N678xA SMU, N6783A-BAT)
