Items Supplied
Power Cord A power cord suitable for your location. Call Keysight Sales & Support Office
Ferrite Core for N6700B Installs on power cord to reduce common mode currents. Keysight 9170-2131
Digital Connector plug 8-pin connector for connecting signal lines to the digital port. Keysight 1253-6408
Phoenix Contact MC 1,5/8-ST-3,5
Product Reference CD-ROM Includes drivers and documentation. Keysight 5969-2914
Automation-Ready CD-ROM Contains Keysight IO Libraries Suite. Keysight E2094N
Quick Reference Guide Contains quick reference information. Keysight 5969-2950
T-10 Torx tool Torx tool for installing or removing power modules. Keysight 8710-2416
8 A Output Connector plug One 8 A, 8-pin connector plug for connecting power and sense
leads. Only used in N678xA SMU.
Keysight 1253-6408
Phoenix Contact MC 1,5/8-ST-3,5
12 A Output Connector plug One 12 A, 4-pin connector plug for connecting power and sense
leads. Used in all except N6731B, N6741B, N6753A-N6756A,
N6763A-N6766A, N6773A, N678xA SMU.
Keysight 1253-5826
Phoenix Contact MSTB 2,5/4-STF
20 A Output Connector plug One 20 A, 4-pin connector plug for connecting power and sense
leads. Only used in N6731B, N6741B, N6754A, N6756A,
N6764A, N6766A, N6773A.
Keysight 1253-6211
Phoenix Contact PC 4/4-ST-7,62
50 A Output Connector plug One 50 A, 2-pin connector plug for connecting power leads. Only
used in N6753A, N6755A, N6763A, N6765A.
Keysight 1253-7187
Molex 39422-0002
AUX Measurement connector
plug
A 2-pin connector plug for connecting the auxiliary measurement
inputs. Only used in N6781A and N6785A.
Keysight 1253-8485
Phoenix Contact FMC 1,5/2-ST-3,5
Small Sense Jumpers Two small jumpers for local sensing at the output connector.
Used in all except N6731B, N6741B, N6753A-N6756A, N6763A-
N6766A, N6773A, N678xA SMU.
Keysight 8120-8821
Phoenix Contact EPB 2-5(1733169)
Large Sense Jumpers Two large jumpers for local sensing at the output connector. Only
used in N6731B, N6741B, N6754A, N6756A, N6764A, N6766A,
N6773A.
Keysight 0360-2935
Phoenix Contact 3118151
Sense Connector A 4-pin connector for connecting sense leads. Wires (p/n 5185-
8847) are used for local sensing. Only used in N6753A, N6755A,
N6763A, N6765A.
Keysight 1253-5830
Phoenix Contact MC 1,5/4-ST-3,5
Module Cal. Certificate A certificate of calibration referenced to the serial number. N/A
When you receive your power system, inspect it for any obvious damage
that may have occurred during shipment. If there is damage, notify the
shipping carrier and nearest Keysight Sales and Support Office
immediately. Refer to www.keysight.com/find/assist
.
Until you have checked out the power system, save the shipping carton
and packing materials in case the unit has to be returned. Check the list
under “Items Supplied” and verify that you have received these items
with your instrument. If anything is missing, please contact your nearest
Keysight Sales and Support Office.
