2 Installation
30 Keysight N6700 User’s Guide
Connecting the Line Cord
Use only the power cord that was supplied with your
instrument. Using other types of power cords may cause overheating of
the power cord, resulting in fire.
SHOCK HAZARD
The power cord provides a chassis ground through a
third conductor. Be certain that your power outlet is of the three-
conductor type with the correct pin connected to earth ground.
Connect the power cord to the IEC 320 connector on the rear of the unit.
If the wrong power cord was shipped with your unit, contact your
nearest Keysight Sales and Support Office.
The AC input on the back of your unit is a universal AC input. It accepts
nominal line voltages in the range of 100 VAC to 240 VAC. The frequency
can be 50 Hz, 60 Hz, or 400 Hz.
Keysight N6702A Mainframe Note:
Standard AC mains circuits rated at
nominal 100-120 VAC cannot supply enough current to power the
N6702A mainframe when it is operated at its full rated power.
Nevertheless, the N6702A can be connected to an AC mains circuit
rated at nominal 100-120 VAC. In this case, internal circuits will limit the
power available to modules to 600 W. As a result of this power limiting,
the current drawn from the AC mains will be < 15 A, so that standard
100-120 VAC mains circuits will not be overloaded.
The detachable power cord may be used as an emergency disconnecting
device. Removing the power cord will disconnect AC input power to the
unit.
