2 Installation
24 Keysight N6700 User’s Guide
General Information
Models
Keysight Model
Description
N6700B / N6701A / N6702A 400 W / 600 W / 1200W MPS Mainframe - without power modules
N6710B / N6711A / N6712A Build-to-order Modular Power System – mainframe with installed power modules
N6731B / N6741B 50 W / 100 W 5 V DC Power Module
N6732B / N6742B 50 W / 100 W 8 V DC Power Module
N6733B / N6743B / N6773A 50 W / 100 W / 300 W 20 V DC Power Module
N6734B / N6744B / N6774A 50 W / 100 W / 300 W 35 V DC Power Module
N6735B / N6745B / N6775A 50 W / 100 W / 300 W 60 V DC Power Module
N6736B / N6746B / N6776A, N6777A 50 W / 100 W / 300 W 100 V DC Power Module
N6751A / N6752A 50 W / 100 W High-Performance Autoranging DC Power Module
N6753A, N6754A / N6755A , N6756A 300 W / 500 W High-Performance Autoranging DC Power Module
N6761A / N6762A 50 W / 100 W Precision DC Power Module
N6763A, N6764A / N6765A, N6766A 300 W / 500 W Precision DC Power Module
N6781A, N6782A, N6784A 20 W Source/Measure Unit (SMU)
N6785A, N6786A 80 W Source/Measure Unit (SMU)
N6783A-MFG / N6783A-BAT 18 W / 24 W Application-Specific DC Power Module
Options
Mainframe
Options
Description
0L1 English Manual Set. Contains User’s Guide and Service Guide. Also available as part number 5969-2939.
908 Rack Mount Kit. For mounting in a 19-inch EIA rack cabinet. Also available as Model N6709A.
FLR Filler module. For mainframes with less than four power modules. Also available as Model N6708A.
Power Module Options
054 High-Speed Test Extensions. Includes digitized output measurements and output list capability.
Available for Models N673xB,- 4xB,-5xA, -7xA. Included with Models N676xA, N678xA SMU, and N6783A.
760
NOTE 1
Output disconnect/polarity reversal. Disconnects the + and – output and sense terminals. Switches the
+ and – output and sense polarities. Not available on N6741B, N6751A, N6752A, N676xA, or N678xA.SMU.
761
NOTE 1
Output disconnect. Disconnects + and – output and sense terminals. Available for all power modules.
UK6 Commercial calibration with test results data
1A7 ISO 17025 calibration certificate
2UA 200 microampere measurement range with output disconnect relays. Only on Models N6761A, N6762A.
J01 Tracking overvoltage protection function. Only available on Models N6752A, N6754A, and N6762A when
installed in an N6700B, N6701A, or N6702A mainframe.
1
A small AC network is always present across the output terminals.
