4 Operating the Power System
98 Keysight N6700 User’s Guide
Front Panel Display
Screen Saver
The power system has a front panel screen saver that significantly
increases the life of the LCD display by turning it off during periods of
inactivity. The delay can be set from 30 to 999 minutes in 1 minute
increments. As shipped from the factory, the screen saver comes on one
hour after activity on the front panel or interface has ceased.
When the screen saver is active, the front panel display turns off, and the
LED next to the Line switch changes from green to amber. To restore the
front panel display, simply press one of the front panel keys. The first
action of the key turns the display on. Subsequently, the key will revert
to its normal function.
If the Wake on I/O function is selected, the display is restored whenever
there is activity on the remote interface. This also resets the timer on the
screen saver. As shipped, Wake on I/O is active.
Select
System\Preferences\Display\Saver
Enable or disable the screen saver by
checking or unchecking the Screen Saver
checkbox. Then Press Select.
Enter a value in minutes in the Saver Delay
field to specify the time when the screen
saver will activate.
Check Wake on I/O to activate the display
with I/O bus activity.
Not Available.
You can set the contrast of the front panel display to compensate for
ambient lighting conditions. The contrast can be set from 0% to 100% in
increments of 1%. As-shipped, the contrast is set to 50%.
Select
System\Preferences\Display\Contrast
Enter a contrast value in the Contrast box.
Then Press Select.
Not Available.
You can specify how the output channels are displayed at turn on.
Select
System\Preferences\Display\View
Check 1-channel to display channel one.
Check 4-channel to display all channels.
To display all channels:
DISP:VIEW METER4
