4 Operating the Power System
74 Keysight N6700 User’s Guide
Step 5.
To generate a pulse train, you can simply repeat the pulse as needed.
For example, to program a pulse train of 50 pulses, use:
Front Panel:
SCPI Command:
Select
Transient\List\Repeat
.
Enter the number of list repetitions
(50) and Press Select.
To program output 1, use
LIST:COUN 50, (@1)
Step 6.
Specify if you want the output pulse to generate a trigger signal that can
be used to trigger actions on other output channels or on any external
equipment connected to the digital port. For example, to generate a
trigger signal at the end of the pulse, use:
Front Panel:
SCPI Command:
Select
Transient\List\Config
.
Select List Step 0 and check the
Tout Step box. Press Select.
To program a trigger at the End
of the pulse for output 1, use
LIST:TOUT:EOST 1,0, (@1)
You must program a value of 0
(no trigger) for step 1 as a
placeholder.
Step 7.
Specify the output state after the pulse has completed. For example, to
return the output to the state it was in before the pulse, use:
Front Panel:
SCPI Command:
Select
Transient\List\Terminate
.
Select Return to Start. Press
Select.
To program output 1, use
LIST:TERM:LAST 0, (@1)
Step 8.
Select the trigger source that will generate the pulse or pulse train. For
example, to select Bus triggers as the trigger source, use:
Front Panel:
SCPI Command:
Select
Transient\TrigSource
.
Select Bus and press Select.
To program output 1, use:
TRIG:TRAN:SOUR BUS, (@1)
Step 9.
Initiate the transient trigger system. To enable the trigger system for one
transient event or trigger use:
Front Panel:
SCPI Command:
Select the
Transient\Control
.
Select Initiate and Press Select.
To program output 1, use
INIT:TRAN (@1)
Step 10.
Trigger the output pulse or pulse train.
Front Panel:
SCPI Command:
Select
Transient\Control
.
Select Trigger and Press Select.
*TRG
