Key Reference
Meas
126
a. Fail Mask is set to Absolute and Rel Stop is set to Couple.
a. Abs Stop is set to Couple and Fail Mask is set to Abs AND Rel.
Tabl e 1 Offsets & Limits Defaulted for W-CDMA (3GPP) Base Station Measurements
a
Offset Start
Freq
(MHz)
Stop
Freq
(MHz)
Res BW
(kHz)
Abs
Start
(dBm)
Abs
Stop
(dBm)
Abs
Couple
Rel
Start
(dBc)
Rel Stop
(dBc)
Meas
BW
A. On 2.515 2.715 30.00 -14.00 -14.00 Couple -30.00 -30.00 1
B. On 2.715 3.515 30.00 -14.00 -26.00 Man -30.00 -30.00 1
C. On 3.515 4.000 30.00 -26.00 -26.00 Couple -30.00 -30.00 1
D. On 4.000 8.000 1000.00
30.00
-13.00 -13.00 Couple -30.00 -30.00 1
33
E. On 8.000 12.500 1000.00 -13.00 -13.00 Couple -30.00 -30.00 1
Tabl e 2 Offsets & Limits Defaulted for W-CDMA (3GPP) Mobile Station Measurements
a
Offset Start
Freq
(MHz)
Stop
Freq
(MHz)
Res BW
(kHz)
Abs
Start
(dBm)
Abs
Stop
(dBm)
Rel
Couple
Rel
Start
(dBc)
Rel Stop
(dBc)
Meas
BW
A. On 2.515 3.485 30.00 -71.07 -71.07 Man -35.23 -49.78 1
B. On 4.000 7.500 1000.0 -55.84 -55.84 Man -35.50 -39.00 1
C. On 7.500 8.500 1000.00 -55.84 -55.84 Man -39.00 -49.00 1
D. On 8.500 12.000 1000.00 -55.84 -55.84 Couple -49.00 -49.00 1
E. Off 12.500 15.000 1000.00 -55.84 -55.84 Couple -49.00 -49.00 1
