Key Reference
System
Diagnostics Accesses the Front Panel softkey to verify the
functionality of each front- panel key. The number next to
each key name increments once each time the key is
pressed. Rotating the knobs causes the number of pulses to
be counted. Press Return will go back to the main menu.
Add Option Accesses the security system to enable
licensing for individual options. A user may not turn off an
option using this system. Once an option has been licensed
for a given analyzer, it cannot be transferred to a different
analyzer.
Port Setting Access the submenu to set the ports as below.
Key access: System > More > Port Setting
Ip Config Toggles the IO port between USB, LAN and
GPIB(option) for remote control.
Probe Power Provides power for high- impedance AC probes
or other accessories (+15 V, –12V, 150 mA maximum).
Key access: System > More > Port
GPIB Address sets the GPIB address (option G01 required).
