120 Keysight N9938-90003 User’s Guide
SA (Spectrum Analyzer) Mode (Option 233–Mixed Analyzers)
SA Mode Settings
—SrcSide Antenna Off / On Edit/Recall an Antenna file to be used to
transmit.
—RcvrSide Antenna Off / On
Edit/Recall an Antenna file to be used to
receive.
—SrcSide Cable Off / On
Edit/Recall a Cable file to be used on the
Source side.
—RcvrSide Cable Off / On
Edit/Recall a Cable file to be used on the
Receiver side.
—View Corrections ON OFF
Turn ON and OFF Pink Trace -
Antenna/Cable corrections. This is a composite of all cable/antenna
corrections that are currently applied. Available as a useful visual aid,
the zero “dB” level (no net correction) is mapped to appear at the
-50 dBm on-screen level.
The following menu appears when any of the above Antenna or Cable softkeys
are pressed:
— Antenna/Cable ON OFF
Turn correction ON or OFF for this Antenna/Cable.
— Edit Antenna/Cable
Edit an Antenna/Cable Correction table. See Using the
Antenna/Cable Editor (below) for more information.
— New
Create a new Antenna/Cable. See Using the Antenna/Cable Editor
(below) for more information.
— Save Antenna/Cable
Save the modified Antenna/Cable to a file on the
specified Storage Device.
— Recall Antenna/Cable
Read an existing Antenna/Cable file from the
specified Storage Device.
— Storage Device
Choose from: Internal, USB, SD. Learn more about these
selections in “Set File Type and Select Device” on page 271.
When finished, press Back
to return to the previous menu.
Using the Antenna/Cable Editor
The Antenna Editor and the Cable Editor menus are very similar. Both tables
include header information, and a Frequency/Value table.
