126 Keysight N9938-90003 User’s Guide
SA (Spectrum Analyzer) Mode (Option 233–Mixed Analyzers)
SA Mode Settings
Volume Control
To increase or decrease the Volume of the demodulated signal:
—Press Meas Setup 4
—Then Volume
Enter a value in percent between 0 and 100 (loudest) using the numeric
keypad, arrows, or the rotary knob.
Volume can also be changed and easily muted from the System
menu.
Learn more in “How to set the FieldFox Volume Control” on page 219.
Demod ON and OFF
To quickly stop the audio demodulation and perform only the normal SA
sweeps, select the following:
—Press Meas Setup 4
—Then Demod ON OFF
Independent Source/Tracking Generator
This feature may require an option. For a comprehensive list, view the FieldFox
Configuration Guide at:
http://literature.cdn.keysight.com/litweb/pdf/5992-3701EN.pdf
A tracking generator, a popular option with Spectrum Analyzers, is a source
which always tracks the SA receiver.
Like a traditional tracking generator, the Independent Source feature can set
the internal FieldFox source to track the SA receiver frequency range. It can
also set the internal source to a CW frequency that is independent of the SA
frequency.
Independent Source can be enabled ONLY when the FieldFox is in SA mode.
To view the internal source, you must connect a cable or device between the
RF Output connector and the RF Input connector.
How to make Independent Source Settings
—Press Measure 1
—Then Source
Source Enable ON OFF
ON Turns ON the internal source.
For best results, when using the independent source feature, InstAlign and
the battery saver features should be turned off. Refer to “How to Access
Individual Alignments” on page 148 and Preferences on page 230.
