274 Keysight N9938-90003 User’s Guide
File Management
Saving and Recalling Files
— Default – SNP data does NOT include smoothing. SNP data saves are taken
AFTER data processing (location 2) on the processing chain.
— Advanced
– SNP data includes the following:
— With Smith or Polar display format, SNP data saves are taken
BEFORE most processing (location 1 on the data processing chain).
— With any other display format, SNP data saves are taken just AFTER
Formatting and Smoothing is applied (location 3 on the data
processing chain). For each non-active trace, SNP trace data is
reprocessed using the data processing chain of the active trace.
See the FieldFox data processing chain at the Supplemental Online Help:
http://na.support.keysight.com/fieldfox/help/SupHelp/FieldFox.htm Learn
more about System Preferences in “Preferences” on page 230.
Manage Files
Files that are stored in the FieldFox internal memory, standard SD card, and
USB Flash drive, can be copied to another device or deleted.
How to Manage files
—Press Save/Recall 9
—Then Device to select the location (Internal, USB, or standard SD Card) of
the file to copy or delete.
—Then More
—Then Manage Files
— Then choose from the following:
— Select Files
Selects a file or files to sort, copy, or delete.
— Sort
— Sort by Name
Sorts the displayed list of files by name.
— Sort by Date
Sorts the displayed list of files by date.
— Copy
Select a file or files to copy.
— Then select a device to copy the file to. Choose from Copy to Internal
, Copy
to USB (must be inserted), or Copy to SD Card (must be inserted).
When selecting Internal, it may also be necessary to first select Manage
Folders to specify an active folder which contains the files to copy or
delete. Refer to “Manage Folders” on page 276
.
