3 CAT (Cable and Antenna Test) Mode
In this Chapter
CAT Mode is typically used to test an entire
transmission system, from the transmitter to the
antenna. This process is sometimes referred to as
Line Sweeping.
CAT Mode is similar to NA (Network Analyzer)
Mode. Learn more in the Supplemental Online Help:
http://na.support.keysight.com/fieldfox/help/SupH
elp/FieldFox.htm
CAT Mode Distance to Fault measurements are
discussed in
Chapter 4, “DTF (Distance to Fault)
Measurements.”
.
IMPORTANT! For CAT and NA modes, limit lines do not apply
where F1 = F2.
“Measurement Selection” on page 39
“Quick Settings Table” on page 40
“Frequency Range” on page 41
“Scale Settings” on page 41
“Averaging” on page 42
“Smoothing” on page 43
“Single or Continuous Measure” on page 43
“Resolution (Number of Data Points)” on page 44
“Sweep Time” on page 44
“Output Power” on page 45
“Interference Rejection” on page 46
“Coupled Frequency” on page 46
