70 Keysight N9938-90003 User’s Guide
NA (Network Analyzer) Mode
NA Mode Settings
How to select a multi-trace configuration
—Press Trace 6
—Then Num of Traces
— Then choose from the following:
The default measurements depend on the options that are installed
How to activate a trace in order to change a setting
—Use the arrows OR
—Press Trace 6
then select Trace 1, Trace 2, Trace 3, or Trace 4, Only traces
that are shown can be activated.
How to maximize the viewing of the active trace
—Press System 7
—Then Full Screen.
— Press any key to return to the standard display.
Quick Settings
Both CAT and NA Modes allow you to view and change most relevant settings
from a single location. All of these settings are discussed in this chapter and,
unless otherwise noted, ALL of these settings can also be made using the
standard softkey menus.
x1
1 trace standard configuration
x2
2 traces overlayed on a single graticule
x2H
2 traces on separate graticules
x3H
3 traces on separate graticules
x3
3 traces overlayed on a single graticule
x4
4 traces overlayed on a single graticule
x4H
4 traces on separate graticules
