Keysight N9938-90003 User’s Guide 23
Preparing for Initial Use of Your New FieldFox
FieldFox High Temperature Protection
— The average temperature that is displayed for the Internal Temperature is
the average of the RF1, RF2, SB1, SB2 temperatures. These temperatures
come from internal sensors embedded within the FieldFox.
The average temperature does not include the CPU or the battery
temperatures. The FieldFox does not measure the CPU and battery
temperatures.
Temperature Control Mode
The FieldFox’s internal temperature control preserves measurement accuracy
and maintains the long-term reliability of the FieldFox. See also, “High-Temp
Shutdown Warning (RTSA Mode Only)” on page 25.
Entering Temperature Control Mode
At an average internal temperature of above approximately 64°C, the FieldFox
enters Temperature Control mode by reducing display intensity. This should
decrease the internal temperature which preserves measurement accuracy and
maintains the long-term reliability of the FieldFox. Refer to Figure 2-1.
In addition, duty cycling is enabled when the internal average temperature of
the FieldFox reaches the duty cycling threshold of above ~64°C. All
applications (except RTSA): Power for internal circuitry is turned off between
sweeps and delaying occurs for the next sweep. In RTSA mode, power is only
turned off, if the FieldFox is in Single Sweep or Hold.
All applications (including RTSA): Display dims to 40% at ~64°C.
For all modes, except RTSA mode, you will see the following messages
displayed for ~3 seconds:
"Automatic Meas Duty Cycling activated for thermal
management"
Later if the temperatures are reduced:
"Temperatures reduced, ending Automatic Meas Duty Cycling"
For RTSA mode (where duty cycling is not possible), you will see the following
messages displayed for ~3 seconds:
"Entering Auto Protect mode for thermal management"
Later if the temperatures are reduced:
"Temperatures reduced, exiting Automatic Protect Mode"
Measurement speed specifications do NOT apply in Temperature Control
Mode.
