Keysight N9938-90003 User’s Guide 79
NA (Network Analyzer) Mode
NA Mode Settings
Sweep Time
The fastest possible sweep time is always used as the default setting. Use the
Min Swp Time setting to slow the sweep time when measuring long lengths of
cable. Learn more at the FieldFox Supplemental Online Help:
http://na.support.keysight.com/fieldfox/help/SupHelp/FieldFox.htm
The actual sweep time is shown on the FieldFox screen. See the Screen Tour
on “Screen Tour” on page 33. To increase the sweep time, enter a value that is
higher than the actual sweep time. The increase will not be exactly the amount
that you enter, as the actual sweep time is the composite of many factors.
How to set Sweep Time
—Press Sweep 3
.
—Then Min Swp Time
.
— Enter a value using the numeric keypad.
— Press a multiplier key. Learn about multiplier abbreviations in “Multiplier
Abbreviations” on page 35.
Triggering
External triggering (NA and SA modes ONLY) allows you to initiate a sweep
when an external DC voltage is sensed at the Ref In/Trig In connector on the
FieldFox top panel. See External Triggering for SA Mode in “Triggering” on
page 136.
Trigger Source
—Press Sweep 3
—Then Trigger
—Then Trig Source
— Then choose from the following:
—Int
(Internal) Sweeps are initiated by the FieldFox internal circuitry.
When Sweep is set to Continuous, a new sweep begins automatically
when the previous sweep ends.
—Ext
(External) A sweep is initiated on the rising or falling edge of an
external TTL signal at the Ref In/Trig In connector on the FieldFox top
panel.
——When the FieldFox is armed for an external trigger signal, Wait
is annotated on the display.
Measurement speed specifications do NOT apply in Temperature Control
Mode. Learn more in
“Temperature Control Mode” on page 23.
