SA (Spectrum Analyzer) Mode (Option 233–Mixed Analyzers)
SA Mode Settings
—Press BW 2.
—Then Advanced
—Then IF Output Use
— Then choose from the following:
—OFF
The translated IF signal at the IF OUT connector is no longer
guaranteed to be centered at 33.75 (Narrow) or 225 MHz (Wide).
Requires Option B04 or B10 respectively.
—Narrow
The IF output signal has approximately 10 MHz bandwidth.
—Wide
Requires B04 or B10. The IF output signal has approximately
100 MHz bandwidth with either B04 or Option B10.
Figure 7-5 SA Display Wide BW IF Out - Center Frequency 4 GHz (Requires Option B10)
