226 Keysight N9938-90003 User’s Guide
System Settings
Utilities
panel. The corrections applied (regardless of mode) are either
default/nominal (if Auto loading was used) or custom/specific (if manual
editing Edit SA was used). Default is OFF.
8. Press Mode
> and then your preferred mode for testing.
— Optional: If you pressed Edit SA in step 6 above and want to display
and to edit a "*.csv" corrections file then:
— Press Scale/Amptd
> More > Corrections > OML Converter
then:
a. Converter
to enable/disable the frequency
converter corrections.
b. Edit Converter
to opens a corrections table of the
currently selected file (*.csv).
To select a setting/value to edit, use the numeric
keypad, arrows, or rotary knob to change
the value.
Refer to Figure 9-4 on page 229.
c. New to opens a corrections table of the currently
selected file (*.csv), but enables you to create a
new converter corrections file. Displays
"Overwrite existing Converter data?"
Then choose:
——Yes
to clear all of the frequency
converter correction table’s values and
enter your own.
——No
to leave the current correction table
values and edit just some of the entries.
To select a setting/value to edit, use the numeric
keypad, arrows, or rotary knob to change
the value.
Refer to Figure 9-4 on page 229.
IMPORTANT! The softkey menu for editing of the frequency converter
correction files is only available when the FieldFox is in SA mode.
It is important to save any changes that are made to the Settings table. If
the Setup Corr softkey is reset to Auto, it will recall the last
"...Default.csv" used, and any unsaved changes will be lost.
