8. Depress the clutch pedal fully .
M55O537A
(1) Clutch Pedal
(A) Depress
To avoid accidents:
Do not release the clutch ped-
al abruptly. The tractor may
start off abruptly, resulting in
rollover.
•
CAUTION
(1) Main Shift Lever (2) Shuttle Lever
(3) Range Shift Lever
9. Change the main shift lever,
M55O556A
POWER SHUTTLE
MANUAL
TF1O503A
range shift lever and shuttle lever
to the position you want.
As this tractor is equipped with the
power shuttle system for forward/
backward driving, it is possible
to shift the main shift and range
shift levers without depressing the
clutch pedal and then operate the
shuttle shift lever.
10. The tractor starts to move if you
release the clutch pedal slowly.
To Next Page
