Tf1O406B
(1) Tachometer / Hourmeter
(2) Fuel Gauge
(3) Engine Coolant Temperature Gauge
(4) Turn Signal Lamp
(5) Engine Oil Pressure Warning Lamp
(6) Battery Charging Lamp
(7) Head Light High Beam Lamp
(8) Glow Plug Indicator
(9) Single brake light
(10) RPM Linked Pedal
(11) Coolant Temperature Warning Lamp
(12) Differential Lock Warning Lamp
(13) PTO Indicator
(14) 4WD Indicator
(15) Quick / Turn Warning Lamp (If Equipped)
(16) Parking Brake Warning Lamp
(17) HMS Lamp
(18) Low Fuel Level Warning Indicator
(19) Air Filter Warning Lamp
(20) ECO PTO Lamp
(21) Auto Level Work Light
(22) No Stall Switch
(23) Cruise Indicator
(24) Speed Limit Switch
(25) Back Up Light
(26) Auto Tilling Depth Work Light
(27) Auto Draft Work Light
(28) Turn Up Light
(29) Calibration Lamp
(30) Communication Error
(31) Cruise PTO Warning Lamp
(32) DPF Warning Light
(33) DPF Progress Light
(34) Engine Check Warning Lamp
(35) Water-In-Fuel Warning Lamp
[ RX7030 ]
