- Visually check the safety relays K5/K6/K7 (deformed contact pins)
- Check the connection KMPRO to KMREL board
Error code : 6
Reset
800 + Ok / Recall
Short text
K5 always inactive!
Long text
K5 permanently inactive!
Description
The control contact of safety relay K5 reports a permanently inactive relay despite having left the zone.
Reaction
General
The control switched into “out of operation 6“
Rope
The control stops in the next possible landing.
Hydraulic
The control stops in the next possible landing and descends into the lowest landing from
there.
Remedy
- Check selection signals SM/SZ (First SZ and then SM must turn active when approaching the zone.)
(Pay attention to the LEDs over the relays)
- Check selection signals for voltage (When a signal is active one should be able to measure a 24V
voltage between the signal and +24V.)
- Check the DIL switch „S1“ on the GENIUS20-relay board (All switches must be positioned on “off”)
- Check the jumper „J3“ (refer to the wiring diagram)
- Visually check the safety relays K5/K6/K7 (deformed contact pins)
- Check the connection KMPRO to KMREL board
Error code : 7
Reset
Automatic
Short text
S1 interruption
Long text
S1 interruption in normal mode
Description
The safety circuit 1 was interrupted during travel.
Reaction
Due to the interruption of the safety circuit the lift is forced to stop and the control switches into “Out-
of-operation” mode.
Causes
- Main switch was switched off
- Safeties MCB FC has triggered
- Speed governor or lift arrestor contact have triggered
- Other contact before the S1 tap has triggered (refer to the wiring diagram)
Remedy
- Measure voltage between S1 and NIN
- If no voltage can be detected, check the safety circuit contacts
- If some voltage can be detected but is not indicated properly by the control it might that the
optocoupler on the KMREL board is defective. Replace optocoupler or KMREL board.
Error code : 8
Reset
Automatic
Short text
S1 interruption
Long text
S1 interruption in inspection mode
Description
The safety circuit 1 was interrupted during travel
Reaction
General
Lift stops and no further inspection run can be carried out
Rope
Hydraulic
Causes
- Main switch was switched off
- Safeties MCB FC has triggered
- Speed governor or lift arrestor contact have triggered
- Other contact before the S1 tap has triggered (refer to the wiring diagram)
Remedy
- Measure voltage between S1 and NIN
- If no voltage can be detected, check the safety circuit contacts
- If some voltage can be detected but is not indicated properly by the control it might that
the optocoupler on the KMREL board is defective. Replace optocoupler or KMREL board.
Error code : 9
Reset
Automatic
