194
MA06-03-1-01
Menu
Hydraulic
The control stops in the next possible lading. Therefrom, the lift descends into the lowest
landing.
Causes
- Main- or brake contactor defective
- Close auxiliary contact of the contactors
- Lock the preselection relay on the KMREL
Remedy
- Replace defective contactor/relay
Error code : 17
Reset
800 + Ok
Short text
Contactor monitor on
Long text
Contactor monitor permanently on
Description
The control recognized the input “MON” after beginning of travel (contactor not energized)
Reaction
General
The control switches into “Out-of-order” mode
Rope
The control stops in the next possible landing.
Hydraulic
The control stops in the next possible lading. Therefrom, the lift descends into the lowest
landing.
Causes
- Main- or brake contactor defective
- Close auxiliary contact of the contactors
- Lock the preselection relay on the KMREL
Remedy
- Replace defective contactor/relay
Error Code: 18
Reset
Automatic
Short text
Err Light Screen D1
Long text
Err Light Screen D1
Description
The control cannot detect a signal at the light curtain input. (Serves to monitor the functioning of the
light curtain according to EN81-20)
Reaction
General
The control switches into “out-of-order” mode.
Rope
Hydraulic
Causes
- Failure or disruption at the light curtain/control unit
- Defective input at the controller
Remedy
- Check light curtain; output function OK must be configurated as a contact maker (N.O.)
- Check wiring
- Check up on the input status-wise
- Should the input be defective it can be re-parameterized to another free I/O at any time
Error code : 19
Reset
Automatic
Short text
Recall UP and DOWN
Long text
Recall UP and DOWN are activ!
Description
Both direction signals apply at the controller even though the recall function is switched off.
Reaction
General
The control switches into “Out-of-order“ mode
Rope
Hydraulic
Remedy
- Let go of the direction switch
- Check wiring
- Check jumper position on the KMPRO board (refer to the wiring diagram) (Jumper
REC/RUP/RDN )
Error code : 20
Reset
Automatic for rope / 800+Ok for hydraulic
Short text
Up final switch
Long text
Final switch upper floor!
