Kleemann GENIUS20 User Manual

56
MA06-03-1-01
Menu
In order to relevel with open doors, the following requirements must apply:
❑ existence of a safety circuit (safety relays K5, K6, K7) on the Genius central electronic unit.
❑ use of a selection system with 2 zone signals.
❑ override of door switches in the zone.
[Direct access: CMD -> 7064]
Parameter
[Direct access]
Description
Default
value
Value Range
Stop distance up vn
(mm)
Stopping distance in upwards direction for
relevelling.
5 mm
0-9999 mm
Stop dist. down vn
(mm)
Stopping distance in downwards direction for
relevelling.
5 mm
0-9999 mm
Relevelling step (mm)
Maximum step at which the levelling process is
initiated.
20 mm
0-9999 mm
Max. relevelling cycle
Maximum number of levelling attempts. After
reaching the maximum number, levelling is
ceased in order to avoid permanent oscillation.
3
0-9999
relevel before travel
Query whether levelling is to be performed
before travelling. When selecting “No”, that
means, if car calls are already active, levelling
is no longer carried out to accelerate
processing, spare the mechanics and save
energy.
NO
YES/NO
O:Bode relay
Determination of an output to control the
Bode descent protection for levelling.
T:Relevel delay (ms)
Time in ms which elapses from stopping to
initiating the levelling process.
1000ms
0-9999 ms
