Kleemann GENIUS20 User Manual

80
MA06-03-1-01
Menu
Parameter
[Direct access]
Description
Default
value
Value
Range
1.O:Gong up
Definition of the first output for gong when travelling
upwards.
1.O:Gong down
Definition of the first output for gong when travelling
downwards.
O: Car position (CP)
Definition of an output address indicating after which
bit-address the car position is to be displayed. On the
hand terminal bus-module page letter “A” indicates
the subsequently required bits. The car position may
be configured using the following 4 parameters.
CP code linear
When “Yes” is selected, the car position is issued in
linear mode. The remaining configuration parameters
for this output type are automatically set to “No”.
NO
YES/NO
CP code binary
When “Yes” is selected, the car position is issued in
binary mode. The remaining configuration
parameters for this output type are automatically set
to “No”.
YES
YES/NO
CP code Gray
When “Yes” is selected, the car position is issued in
Gray code. The remaining configuration parameters
for this output type are automatically set to “No”.
NO
YES/NO
CP code starts with 1
The start value can be determined for all output
types. When “Yes” is selected, it starts with 1; for “No”
with 0.
YES
YES/NO
The parameters of the submenu “Door side 2” are exactly the same with the ones for “Door side 1”.
