P-Q assignment: to specify the function associated with P-Q output.
• This output is default assigned to « AUX A » changeable in the
menu « AUX A designation » (see below).
• This output can also be assigned as heating output.
S-SN assignment: to specify the function associated with pH output.
• This output is default assigned as « pH »
• This output can also be assigned as « AUX 1» or « disinfectant »
output.
R-RN assignment: to specify the function associated with disinfectant output.
• This output is default assigned as « disinfectant ».
• This output can also be assigned as « AUX 2» output.
M/K-KN assignment: to specify the function associated with the double-relay output
(flocculant, lighting or auxiliary B). This output is default assigned as
« lighting ».
Aux.A.(AuxB) designation: to specify the type of equipment connected to auxiliary A output:
booster pump, spa, blower, outdoor lighting, fountain, CC swim, water blade, watering, UV,
motorized valve. This is purely informative and has no influence on Klereo operational mode.
If other auxiliaries have been set up (in place of disinfectant and/or pH), their designation will
appear in the menu after « Aux.A designation ».
5.13 Heating
Important: only assign P-Q output as heating in case of « other heating ». When using a
Klereo heating pump, you only have to connect the “lin” bus (refer to § 5.13.3).
Two « heating » sub-menus are available, one to select the type of heating (go to menu
parameters / set-up) and the second to select the operational mode and the water
temperature (go to menu Klereo / heating or through the home screen by selecting the
heating icon).
5.13.1 Heating set-up
Go to menu « Heating type» to set up the type of heating used in the installation. It is default
set up « other heating ».
