5.16.1 Flow switch
The flow switch can be set up for the following functions:
• Pump protection: to secure the filter pump by stopping it in case of low water flow
rate. Default selected when delivered.
• Analysis valid.: to enable analysis when a sufficient water flow rate is detected. In
case of too low water flow rate, measured values are disabled and regulation is
stopped.
• Treatment valid.: to authorize water treatment when a sufficient water flow rate is
detected. In case of too low water flow rate, water treatment is stopped.
• None
5.16.2 220V input
The 220V input can be set up as follows:
• Two-way switch: to pilot lighting
• Push-button: to pilot lighting
• Force filtering: forces filtering in case of 220V input
• Prevent filtering: prevents filtering in case of 220V input
• Authorize filtering: authorize filtering in case of 220V input (useful when using
automatic valve for backwash system)
• Slave filtering: to use the Kompact control box unit in slave mode. In this setting-up,
filtering is ON when there is 220V input and OFF on the contrary.
5.16.3 Inputs status
To check I-J 220V input status as well as empty tank level detectors (for pH and disinfectant)
when used.
5.17 Programming modes for filtering, lighting and auxiliaries outputs:
Filtering
Regulated Filtering regulated according to water temperature
Time slots Operation programmed in time slots
Manual Always ON or OFF
Lighting
Timer Automatically turned off at the end of the setup time.
Time slots Operation programmed in time slots
Manual Always ON or OFF
The Force filtering mode is available in the lighting and auxiliary functions.
It enables filtering to be started up at the same time as the operating periods defined for
lighting and/or auxiliary systems outside the filtering periods calculated or planned for
treatment.
On the opposite, auxiliaries can work at the same time filtering works. In that case select the
« Filt. synch.» (synchronized with filtration) mode.
