101
When the delivery also includes the Klimor control system,
the air volume for gear 3 shall be adjusted so that the air
volume are not less than those given in the table for the full
performance of the HPM/CM system (Tab. No. 25). For lower
air capacity (gears 2 and 1), HPM systems can operate at re-
duced cooling capacity. For gears 2 and 1, the minimum air
volume are shown in Tab26.
Tab. Nr 26 Minimum air volumes required for HPM and CM refrigeration at limited capacity
HPM.i ; CM.i
Unit size
System
symbol
Air ow rate
min. [m
3
/h]
Number of rows of ex-
changer at the exhaust
0300 25 1200 6
0300 25 700 8
0300 43 1200 8
0400 43 1000 8
0400 43 1800 6
0400 71 2000 8
2500 43 1300 8
2500 43 1700 6
2500 71 1800 8
3500 43 1300 8
3500 43 1700 6
3500 71 1800 8
0600 43 1600 8
0600 43 1900 6
0600 71 2200 8
0600 71 3100 6
0600 113 3200 8
0700 71 1900 8
0700 71 2800 6
0700 113 3100 8
5800 71 2400 8
5800 71 3000 6
5800 113 3300 8
8800 71 2400 8
8800 71 3000 6
8800 113 3300 8
0010 113 2800 8
0010 113 4300 6
0010 143 4500 8
0010 143 5500 6
0010 185 5500 8
5010 113 2800 8
5010 113 4300 6
5010 143 4500 8
5010 143 5500 6
5010 185 5500 8
5310 143 4300 8
5310 143 5300 6
5310 185 5500 8
5310 185 7000 6
5310 257 7700 8
Unit size
System
symbol
Air ow rate
min. [m
3
/h]
Number of rows of ex-
changer at the exhaust
4410 143 4300 8
4410 143 5300 6
4410 185 5500 8
4410 185 7000 6
4410 257 7800 8
5610 185 5300 8
5610 185 6500 6
5610 257 7500 8
5610 257 10000 6
5610 329 10000 8
0020 257 7000 8
0020 257 9500 6
0020 329 10000 8
0020 393 13000 8
0120 257 7000 8
0120 257 9500 6
0120 329 10000 8
0120 393 13000 8
5320 329 9000 8
5320 329 13000 6
5320 393 12000 8
5320 393 15000 6
5320 435 14000 8
0720 393 11000 8
0720 393 13500 6
0720 435 13500 8
0720 435 16000 6
0720 533 16000 8
0230 393 11000 8
0230 393 13000 6
0230 435 13000 8
0230 435 16000 6
0230 533 16000 8
0530 435 14000 8
0530 435 15000 6
0530 596 18000 8
0530 596 22000 6
0530 673 22000 8
0930 533 16000 8
0930 533 18000 6
0930 673 22000 8
0040 596 18000 8
0040 596 22000 6
0040 673 22000 8
0040 673 26000 6
0040 757 26000 8
0050 596 18000 8
0050 596 22000 6
0050 673 22000 8
0050 673 26000 6
0050 757 26000 8
