F7 and F9 bag filters
The F7/F9 bag filters are designed for secondary air treat-
ment.
The filters are mounted in guides with seals and a slat
clamp that is locked on an eccentric connection mech-
anism (Fig. 42).
Separators from the metal section with seals are mounted
between the filters.
When replacing the filters, it is recommended to replace
the self-adhesive seal fixed inside the guide.
F7/F9 bag filters are not to be regenerated and he be re-
placed with new ones.
The dimensions of the filters used are specified in the KT
certificate.
Table 16. Dimensions and quantities of bag lters
Size
EVO
W H Pcs. Size
EVO
W H Pcs.
[mm]  [mm] 
5100 600 350 1 5610 629 1150 3
3200 422 350 2 0020 570 1150 4
5200 600 550 1 0120 560 821 6
0300 422 450 2 5320 570 1350 4
0400 547 450 2 0720 629 921 6
2500 597 550 2 0230 670 771 8
3500 422 800 2 0530 745 771 8
0600 597 650 2 0930 762 1121 6
0700 697 650 2 0040 745 921 8
5800 697 800 2 0050 895 921 8
8800 547 1050 2 0060 895 1121 8
0010 797 797 2 0070 970 1171 8
5010 597 1150 2 0090 1120 1321 8
5310 560 1050 3 0001 1195 1321 8
4410 697 1350 2 0021 1270 1471 8
Table 16a Standard dimensions and quantities of bag lters
Size
EVO*
W H Pcs W H Pcs W H Pcs
[mm]  [mm]  [mm] 
5200 592 490 1
2500 592 490 2
3500
490 490 1 287 490 1 490 287 1
287 287 1
0600 592 592 2
0700 592 592 1 490 592 1 287 592 1
5800
592 490 1 490 490 1 287 490 1
592 287 1 490 287 1 287 287 1
8800 592 490 2 490 490 2
0010
592 490 1 490 490 2 592 287 1
490 287 2
5010 592 592 2 592 490 2
Size
EVO*
W H Pcs W H Pcs W H Pcs
[mm]  [mm]  [mm] 
5310 592 490 4 490 490 2
4410
592 490 2 490 490 2 287 490 2
592 287 1 490 287 1 287 287 1
5610
592 592 1 490 592 2 287 592 1
592 490 1 490 490 2 287 490 1
0020
592 592 3 490 592 1 592 490 3
490 490 1
0120
592 592 2 490 592 1 592 490 4
490 490 2
5320
592 490 6 490 490 2 592 287 3
490 287 1
0720 592 592 3 490 592 6 287 592 3
0230
592 592 8 592 287 4 287 592 2
287 287 1
0530 592 592 10 592 287 5
0930
592 592 6 592 490 6 490 592 2
490 490 2
0040 592 592 15
0050 592 592 18
0060 592 592 12 592 490 12
0070
592 592 18 592 490 6 287 592 3
287 490 1
0090
592 592 21 592 490 7 592 287 7
287 592 3 287 490 1 287 287 1
0001 592 592 24 592 490 8 592 287 8
0021
592 592 32 592 490 8 287 592 4
287 490 1
*) does not apply to KLIMOR EVO size centrals: 5100, 3200, 0300 and
0400)
Mounting of F7/F9 bag and minipleat lters in guides.
1. Pull the slider towards you, lock the sliders of the guides
(mandrel Ø4x40).
2. Fold the lter bags. This prevents the bags from getting
caught in the guide elements.
3. Slide the lters into the guide using sealing separators.
4. Remove the guide locks.
5. Push the lter and slide the slider as far as it will go.
6. Lock the pressed slider
Separators mounted between the lters are not
included in the service equipment and cannot by
replaced with new ones. Therefore, when repla-
cing the lters, they must be secured for reuse.
Lack of separators will result in bypass air ow
bypassing the lters.
