Temperature points—The following analog value objects represent
temperatures points derived from the AppStat input sensors.
Value object Name Description
AV1 SPACE_TEMP Space Temperature
AV19 OUTDOOR_TEMP Outdoor Air Temperature
AV20 DISCHARGE_TEMP Discharge Air Temp
AV21 REL_HUMIDITY Relative Humidity
Table 7–7 Analog value objects—Temperature points
Economizer and heat pump unit setpoints—The following analog value
objects represent setpoints for AppStat heat pump unit and economizer
operation.
Value
object
Name Description
AV13 DAT_RESET Discharge Air Reset STPT
AV14 MIN DAT Min Discharge Air Temp
AV15 MIN_ECON_DAMPER Minimum Econ Damper
AV16 ECON_ENABLE_
TEMP
Economizer Enable Temperature
AV17 CMP_LOCKOUT Compressor Lockout
Temperature
AV18 AUX_HT_LOCKOUT OAT AUX Heat Lockout
Table 7–8 Analog value objects—Economizer and HPU setpoints
Operating states and modes—The binary and multistate value objects
represent operating conditions in the AppStat. Objects BV5 and BV36 are
releated to the schedule.
Value object Name Description
BV5 OCC_SCHEDULE Occupy Schedule
BV13 OCCUPIED_FAN Fan On During Occupied Mode
Table 7–9 Binary value objects
Section 7: System integration KMC Controls, Inc.
118 Revision G
