KMC Controls BAC-4000 series User Manual

10 m
32.8 ft
10 m
32.8 ft
0°
46.5
°
Y
55
°
10 m
32.8 ft
10 m
32.8 ft
X
0°
Side viewTop view
Installation
accessories
The following accessories are available from KMC Controls, Inc.
XEE-6111-040 Single-hub 120 volt power transformer
XEE-6112-040 Dual-hub 120 volt power transformer
XEE-6311-075 120/240/277/480VAC, 24 VAC, 75 VA transformer
HMO-10000W White mounting plate kit for retrofit on horizontal
boxes or 4 x 4 handy boxes
Section 1: Introduction to the AppStat KMC Controls, Inc.
12 Revision G
