Setting the
occupancy schedule
The schedule in the AppStat controls the occupancy mode. If the schedule is
set to ON, the AppStat uses the occupied setpoint as the active setpoint. If the
schedule is OFF, the unoccupied setpoint is used.
Note: The schedule in the AppStat is a BACnet schedule object. If the AppStat is
connected to a BACnet network the schedule can be set up with a BACnet
operator workstation.
Setting the occupancy schedule requires entering Password2 which is
described in the topic Enter the commissioning mode on page 40.
To change the time and date, see the procedure Set the time and date on page
45.
Procedure Steps Display
1 Starting display
1.
Start at the temperature display.
2.
Enter Password 2. The display changes to the
MAIN menu display.
F
°
70
AUTO AUTO
SECURITY
ADMIN LEVEL
0 0 0 0
2 Select the
SCHEDULE menu.
1.
From the MAIN menu , press either the or
button to select SCHEDULE.
2.
Press Enter. The SCHEDULE menu opens.
MAIN
SETPOINT
SCHEDULE
SYSTEM
COMM
ADVANCED
BackEnterExit
Set up schedules
Installation, Operation, and Application Guide for AppStat Section 4: Commissioning functions
Revision G 47
