Set up
communications
Setting BACnet communications properties is required only if the AppStat is
integrated into a network with other BACnet controllers. Entering the
communications properties requires entering Password 2 which is described
in the topic Enter the commissioning mode on page 40.
See the topic Connecting to an MS/TP network on page 121 for network
wiring details.
Procedure Steps Display
1 Starting display
1.
Start at the temperature display.
2.
Enter Password 2. The display changes to the
MAIN menu display.
F
°
70
AUTO AUTO
SECURITY
ADMIN LEVEL
0 0 0 0
2 Change the network
communication
properties.
1.
From the MAIN menu , press either the or
button to select COMM.
2.
Press Enter. The COMMmenu opens.
3.
Choose and set the following properties.
l DEVICE ID—This is the BACnet device
instance. The device instance must be
within the range of 1 to 4,194,302.
l MAC—The MAC address must be in the
range of 1-127.
l BAUD—Set to match other devices on
the BACnet MS/TP network. The choices
are Auto, 9600, 19,200, 38,400, or 76,800.
Note: After changing a communication
property the AppStat will reset.
MAIN
SETPOINT
SCHEDULE
SYSTEM
COMM
ADVANCED
BackEnterExit
COMM
DEVICE ID
MAC
BAUD
BackEnterExit
D ID: 0000001
DoneEnterEnter
Set BACnet communication properties
Installation, Operation, and Application Guide for AppStat Section 4: Commissioning functions
Revision G 43
