Output objects
The following BACnet output objects represent values at the physical outputs
of the AppStat. For output wiring details see Connecting outputs on page 24.
For application specific wiring details see the section Application drawings on
page 77.
Note: Not all objects are present in every model.
Output Name Description Device type
AO6 VALVE Analog Valve Output 0-100% (0-10 V)
AO7 AUX HEAT Auxiliary Heat 0-100% (0-10V)
AO8 FAN_SPEED_AO Fan Speed Control 0-100% (0-10V)
BO1 LOW Fan Low Speed Unknown
BO1 FAN_START_STOP Fan Start/Stop Unknown
BO2 MEDIUM Fan Medium Speed Unknown
BO3 HIGH Fan High Speed Unknown
BO4 VALVE Valve Unknown
BO5 AUX HEAT Auxiliary Heat Unknown
Table 7–2 Fan coil unit, two-pipe
Output Name Description Device type
AO6 COOLING_VLV Analog Cooling Output 0-100% (0-10 V)
AO7 HEATING_VLV Analog Heating Output 0-100% (0-10 V)
AO8 FAN_SPEED_AO Fan Speed Control 0-100% (0-10V)
BO1 LOW Fan Low Speed Unknown
BO1 FAN_START_STOP Fan Start/Stop Unknown
BO2 MEDIUM Fan Medium Speed Unknown
BO3 HIGH Fan High Speed Unknown
BO4 COOLING_VLV Cooling Valve Unknown
BO5 HEATING_VLV Heating Valve Unknown
Table 7–3 Fan coil units, four-pipe
Installation, Operation, and Application Guide for AppStat Section 7: System integration
Revision G 115
