AppStat model
numbers
Use the following charts to identify features in a specific AppStat model.
Fan coil units—The model numbers for these controllers end with "0001".
The inputs, outputs, and sequences of operation are configured and
programmed for the following functions.
Two-pipe heating and cooling with on/off valves, modulating valves or
both
Four-pipe heating and cooling with on/off valves, modulating valves or
both
Three-speed or modulating fan control
Automatic or manual fan control
Remote space temperature sensor
Local temperature setback mode based on optional built-in motion
sensor
Dehumidification on models with humidity sensor
See the following chart for the specific features included with each model.
Illustration 1–1 Model numbers for fan coil units
BAC-4 _ _ _ CW0001
1 3-speed fan, On/off valves
2 3-speed fan, Modulating valves
3 3-speed or modulating fan,
modulating or On/Off valves
7 Modulating fan, On/Off valves
8 Modulating fan, Modulating Valves
0 Without humidity
2 With humidity
0 Without motion
2 With motion
Installation, Operation, and Application Guide for AppStat Section 1: Introduction to the AppStat
Revision G 13
