KMC Controls BAC-4000 series User Manual

Set heat pump unit
system options
The items in the system menu control application specific functions for heat
pump units. Entering the system options requires entering Password 2 which
is described in the topic Enter the commissioning mode on page 40.
Procedure Steps Display
1 Starting display.
1.
Start at the temperature display.
2.
Enter Password 2. The display changes to the
MAIN menu display.
F
°
70
AUTO AUTO
SECURITY
ADMIN LEVEL
0 0 0 0
2 Choose and set the
heat pump system
options.
1.
From the MAIN menu , press either the or
button to select SYSTEM.
2.
Press Enter. The SYSTEM menu opens.
3.
Choose any of the following items.
LOCAL OVRD TIME
FAN OFF DELAY
OCCUPIED FAN
MIN OFF TIME
STAGE DELAY
ECON ENABLE (optional)
MIN ECON DAMPER (optional)
ECON ENABLE TEM (optional)
MIN DAT (optional)
REV VLV PLRTY
AUX HEAT (optional)
AUX HT LOCKOUT (optional)
COMP LOCK TEMP
DEHUM ENABLE (optional)
MAIN
SETPOINT
SCHEDULE
SYSTEM
COMM
ADVANCED
BackEnterExit
BackEnterExit
SYSTEM
LOCAL OVRD TIME
FAN OFF DELAY
OCCUPIED FAN
MIN OFF TIME
STAGE DELAY
ECON ENABLE
MIN ECON DAMPER
SYSTEM
ECON ENABLE TEM
MIN DAT
REV VLV PLRTY
AUX HEAT
AUX HT LOCKOUT
COMP LOCK TEMP
DEHUM ENABLE
BackEnterExit
Set up heat pump unit system options
Section 4: Commissioning functions KMC Controls, Inc.
56 Revision G
