Value object Name Description
BV14 FAN_STATUS Fan Proof
BV28 LOCAL_OVRD Local Override Mode
BV36 STPT_HOLD Hold Temperature Setpoint
Binary value objects (continued)
Value object Name Description
MSV1 OCCUPIED_MODE Occupied Mode
MSV2 SYSTEM_MODE Control Mode
MSV3 FAN_MODE Fan Auto-Manual Mode
Table 7–10 Multistate value objects
Schedule object
The AppStat occupancy state is controlled from a standard BACnet schedule
object. The occupancy state is stored in the reference object binary value
object OCC_SCHEDULE. The exception schedule within the schedule object is
represented in the user interface as the holiday schedules.
Object Name Description Object reference
1 SCHED_1 Schedule #1 BV5 (OCC_SCHEDULE)
Table 7–11 Schedule object
Loop objects
The BACnet PID loops are used for valve and fan modulation, staging,
economizer operation, and reheat during dehumidification. The proportional
and integral properties of the cooling and heating loops are available from
the user interface.
Note: Not all objects are present in every model.
Installation, Operation, and Application Guide for AppStat Section 7: System integration
Revision G 119
