Se c tion 6: A pplicatio n dr aw ing s
This section covers the drawings, materials, and instructions for specific
AppStat applications.
Each AppStat model is designed for a specific application. The following
topics are for control technicians and engineers that will plan and install
AppStat controllers for the following applications.
Fan Coil Unit applications on page 78
Roof Top Unit applications on page 98
Heat Pump Unit applications on page 108
