Procedure Steps Display
7 Set fan speeds for
modulating speed
fans.
Select FAN MINIMUM or FAN MAXIMUM
from the SYSTEM menu to set fan speed for
modulation fans.
FAN MINIMUM—Sets the slowest speed at
which the fan will run when a user sets the
fan speed to LOW.
FAN MAXIMUM—Sets the fastest speed at
which the fan will run when a user sets the
fan speed to HIGH.
The MED speed is automatically set halfway
between the LOW and HIGH settings.
BackEnterCncl
FAN MINIMUM:
35 %utoz
BackEnterCncl
FAN MAXIMUM:
100 %utoz
8 Set fan speeds for
three-speed fans.
Select FAN SPEEDS from the SYSTEM menu to
designate the number of speeds at which the
installed fan will run.
BackEnterCncl
FAN SPEEDS:
THREE SPEEDS
TWO SPEEDS
SINGLE SPEED
9 Enable auxiliary heat
Choose AUX HEAT from the SYSTEM menu to
enable auxiliary heat in two-pipe applications.
AUX HEAT:
Enable
Disable
DelEnterCncl
Set up fan coil unit system options (continued)
Section 4: Commissioning functions KMC Controls, Inc.
52 Revision G
