SECTION 9
HYDRAULIC SYSTEM
Dec 2002
Page 9-6
05114640
9.3 Motor/Hydraulic Service Maintenance
The hydraulic oil filter should be checked daily and replaced when the visual
indicator is in the red zone. The hydraulic oil should be replaced every 2000
hours or yearly, whichever occurs first. For hydraulic oil and filter
maintenance, see Section 10, Recirculation System.
The hydraulic system components that require periodic maintenance are the
motor and the manifold. The motor needs to be serviced every 5000 hours of
use. The operating pressure settings of the manifold needs to be checked daily
and adjusted if necessary.
Recommended Tools: Manual Grease Gun
Open End Wrench 14mm (9/16”)
Rags
Parts: Bearing Grease, SRI #2 or equivalent
Item Description
(1) Motor (2) Manifold (3) Recirculation Pump
(4) Hydraulic Pump
