SECTION 3
OPERATION
Nov 2002
Page 3-4
05114582
3.2.2 Operating Procedures
The display on the operator’s console provides information and diagnostics.
The following pages show start, stop and fault recovery procedures. The display
messages are shown in a box representing the actual display.
The display language is set by pressing function key F8 (14); scroll by pressing
F8 until necessary language (abbreviation displayed between brackets) is found.
START PROCEDURE
1. Pull EMERGENCY STOP (ES) PALMBUTTON (6).
2. Push CONTROL POWER ON button (5).
CONTROL POWER ON button (5) light will be ON. Display (9) will be ON.
3. Display Messages:
First
5 Seconds Later
F1 light (8) will go ON.
4. Push F1 (8) – motor starts and after a delay pump starts.
F1 LED turns OFF
F5 LED will be ON
CONTROL POWER ON light will be ON
RUN green light will be ON
Message:
LDU L60 V 1.2
E2 SIZE = 8K
SLIV100-1 (ENG)
10.0 HRS
SLIV100-1 (ENG)
10.0 HRS
To Next Page
