SECTION 11
SPECIFICATIONS
Jan 2003
Page 11-4
05114665c
11.2 Torque Specifications
Recommended Torque Values–Hydraulic Intensifier and HP Connections
Do not exceed torque values, excess torque can cause
component damage or failure with potential hazards to
equipment and personnel.
Item Torque Nm(Ft-Lb)
Wrench mm(inch)
Hydraulic Intensifier
Hydraulic Cylinder
End bell bolt 200(145) M12 hex
Proximity switch 17(13) M5 hex
Seal Head
Gland Nut 88(65) 30 (1-3/16) Crowfoot
HP Tubing Nut 67(50) (13/16) Crowfoot
Pneumatic Valve
3/8" Inlet 67(50) (13/16) Crowfoot
1/4" Outlet 34(25) (5/8) Crowfoot
H P Fitting Gland Nuts
1/4" Nut 34(25) (5/8) Crowfoot
3/8" Nut 67(50) (13/16) Crowfoot
9/16" Nut 149(110) (1-3/16) Crowfoot
NOTE
Measurements are made with lubricated components and a calibrated
torque wrench. Inconsistencies in wrench settings, lubrication, and
technique, may not produce a leak tight seal. If leakage persists,
increase the torque until the components seal, do not exceed a value
15% greater than shown. If leakage persists there is a component
problem. EXCESSIVE TORQUE MAY DAMAGE OR REDUCE THE
LIFE OF COMPONENTS.
Use of an antiseize thread lubricant, like High Purity Goop
(P/N 10084440) is highly recommended for tightening of stainless
steel HP water fittings.
A torque wrench kit is available from (P/N 49895436).
W
ARNING
!
