3.5.3 Low Oil Level Shutdown
1. The unit will shut down immediately and the following occurs due to low oil
level:
• RUN green light will go OFF
• MALFUNCTION red light will go ON
• F1 will be ON
• F6 will be ON
2. The display sequence will read:
CHECK LEVEL GAGE
PUSH F6 TO RESET
3. To correct the condition do the following:
• Fill to proper level
• Observe all safety procedures
• Check for cause of low level, leaks, etc.
• Make required repairs
4. After problem is corrected the following occurs:
• Push F6 to clear the messages.
• MALFUNCTION red light should go OFF
• F1 LED will be ON
• F6 LED will go OFF
5. Push F1 and follow the START procedure to resume normal operation.
3.5.4 High Booster Temperature Shutdown
The unit will shutdown after 30 seconds of over temperature.
1. The RUN green light will go OFF and the MALFUNCTION red light will go ON
when the booster temperature is too high.
2. The display sequence will read:
LONG STALL?
INLET WATER?
PUSH F6 TO RESET
3. To correct the condition open the nozzle valve to allow cutting water to flow
and let the unit cool down. Check the low pressure water (inlet water).
4. After the problem is corrected the following occurs:
• MALFUNCTION Red light should be OFF
• F1 LED will be ON
• F6 LED will be ON
5. To resume normal operation:
• Push F6 and the messages will clear
• The F1 LED will be on and all others will be OFF
• Push F1 and follow the START procedure
OIL LEVEL LOW
CHECK LEVEL GAGE
BOOSTER TEMP HIGH
LONG STALL?
