SECTION 3
OPERATION
Nov 2002
Page 3-13
05114582
3.5.5 High Pressure Leak Warning
The high pressure leak warning will occur for at least 60 seconds before
the unit shutdowns. It is possible for the unit to run indefinitely with a
high pressure leak warning
1. The following will occur as a warning to the operator of the unit’s condition:
• MALFUNCTION red light blinking
• RUN green light ON
• F5 LED ON
2. The unit will shutdown:
• Run green light goes OFF
• MALFUNCTION red light ON steady
• F1 LED will go ON
• F6 LED will go ON
3. The display sequence will read:
CHECK H.P. CHECK VALVES
CHECK H.P. SEALS
CHECK ORIFICE
CHECK FITTING
CHECK TUBING
PUSH F6 TO RESET
4. Correct the condition by checking the items on the display.
5. After the condition is corrected, the following occurs:
• Push F6 to clear messages
• MALFUNCTION red light should go OFF
• F1 LED will be ON
• F6 LED will go ON
6. To resume normal operation:
• F1 LED will be ON and all others will be OFF
• Push F1 and follow the START procedure
H.P. WATER LEAK
CHECK H.P. CHECK VALVES
To Next Page
