SECTION 11
SPECIFICATIONS
Nov 2002
Page 11-1
05114665
11 Specifications
Following are the specifications for the SL-IV 100D Waterjet Pump. Included
are the specifications for the equipment, torque, cutting water, cooling water,
and the maximum quantity of orifices that can be supported.
11.1 Equipment Specifications
Installation location
Indoors
-Air borne dust/contaminants Min
Ambient temperature
-Minimum storage 2(36)
°C(°F)
-Minimum operating 5(40)
°C(°F)
-Maximum operating
1
40(104)
°C(°F)
Maximum Relative Humidity
2
-At Maximum Operating Temp. 95%
Electrical
3
Motor Size 75 (100) Kw (hp)
-Motor type
4
TEFC
Voltage / Service Amps
400/3/50/150
Volts/Phase/Hertz/Am
ps
415/3/50/15
0
480/3/60/15
0
575/3/60/15
0
Controls
-Voltage 24 volts, DC
-Power Supply 10 amps, DC
-Safety shutdown switch settings
High oil temperature 62(144)
°C(°F)
Low oil level 140(37) l (gal).
Boost pump overheat 53(128)
°C(°F)
Hydraulic System
-Oil tank capacity 170(45) l (gal)
-Recommended oil type
Regular applications
1
Based on motor nameplate data, oil temperature must be maintained within operating
specifications.
2
When relative humidity is above 50%, frequently check oil in tank for water content.
Installation of an air desiccant trap/filter on the oil tank breather is a good practice.
3
Totally enclosed fan cooled.
4
Not all motor voltages are readily available, check with factory for availability
