KMT STREAMLINE SL-IV 100 User Manual

SECTION 11
SPECIFICATIONS
Jan 2003
Page 11-2
05114665c
Food applications Mobil, DTE Heavy Medium,
# 021029 (KMT# 05022702)
AMOCO #FG68EL (KMT# 10192524)
-Hydraulic oil operation
Minimum temperature 15(60)
°C(°F)
Maximum temperature 65(150)
°C(°F)
Optimum temperature 46(115)
°C(°F)
Hot oil shutdown
62(144)
°C(°F)
Oil filtration
β
10
>75
-Hydraulic Pump Type Piston
Displacement
Variable
Pressure
Compensated
Flow rate 203(53) l/min(gpm)
-Hydraulic Hi-Lo Settings (factory)
Lo pressure 34(500) bar(psi)
Hi pressure 172(2500) bar(psi)
-Hydraulic oil cooling
Total heat rejection 13(18) kW(hp)
Cooling fluid requirements at
inlet fluid temperature
18(65)
°C(°F)
Maximum cooling flow 17(4.5) l/min(gpm)
Maximum inlet pressure 6.9(100) bar(psi)
Pressure drop 30(2) bar(psi)
Cutting Water "IN"
-Minimum inlet pressure 2.4(35) bar(psi)
-Maximum inlet pressure 7(100) bar(psi)
-Maximum outlet pressure 8.3(120) bar(psi)
-Maximum inlet temperature 29(85)
°C(°F)
-Optimum inlet temperature 18(65)
°C(°F)
-Factory Boost Pump Settings
Inlet Pressure 4(58) bar(psi)
Outlet Pressure Set at
5
8.3(120) bar(psi)
Cutting Water Out
-Maximum flow rate
7.6(2.0)
l/min(gpm)
-Minimum outlet pressure 345(5,000) bar(psi)
-Maximum cont. outlet pressure 3800(55,000) bar(psi)
Compressed Air
-Flow rate maximum 0.028(1.0) m
3
/min(cfm)
-Inlet pressure range 5-6(75-85) bar(psi)
Service Connections
-Cutting water in 1/2" NPT
5
Boost pump discharge pressure is dependent on inlet pressure.
