User manual - DATA RECORDER and cooperating software
Parameters of TC, RTD and mV type inputs ( mV/
RTD/TC version
)
Thermocouple input
K, S, J, T, N, R, B, E
Measurement ranges K:
S:
J:
T:
N:
R:
B:
E:
-200 °C
-328 °F
-50 °C
-58 °F
-210 °C
-346 °F
-200 °C
-328 °F
-200 °C
-328 °F
-50 °C
-58 °F
250 °C
482 °F
-200 °C
-328 °F
÷
÷
÷
÷
÷
÷
÷
÷
÷
÷
÷
÷
÷
÷
÷
÷
1370 °C
2498 °F
1768 °C
3214 °F
1200 °C
2192 °F
400 °C
752 °F
1300 °C
2372 °F
1768 °C
3214 °F
1820 °C
3308 °F
1000 °C
1832 °F
Measurement accuracy K, J, E: ± 0.1% @ 25 °C; ± one digit
N: ± 0.2% @ 25 °C; ± one digit
S, T, R, B: ± 0.5% @ 25 °C; ± one digit
Accuracy of cold ends temperature
compensation ± 1 °C
RTD input
Pt100, Pt500 or Pt1000 (with manual connection
switch 2 or 3-wire)
Measurement range -100 °C ÷ +600 °C
-148 °F ÷ +1112 °F
Measurement accuracy ± 0.1% @ 25 °C; ± one digit
Measurement wires resistance
max. 20 W (every wire)
Voltage input (150 mV)
0÷60 mV, 0÷75 mV, 0÷100 mV, 0÷150 mV
Measurement accuracy ± 0.1% @ 25 °C; ± one digit (for 0÷150 mV range)
Input resistance
> 1,5 MW
Accepted prolonged input overload 20,00%
Temperature stability 50 ppm / °C
Display range -999 ÷ 9999 (for RTD mode – see above)
Common ground
10
