Kobold ZLS-2 - 4.3. CONNECTION METHOD

User manual - DATA RECORDER and cooperating software
Fig. 4.4. Connectors removing method
Fig. 4.5. Minimum distances when assembly of a number of units
4.3. CONNECTION METHOD
Caution
- Installation should be conducted by qualified personnel. During installation all
available safety requirements should be considered. The fitter is responsible for
executing the installation according to this manual, local safety and EMC
regulations.
1
5
!
115 mm
115 mm
back side
of device
connector
GOOD
back side
of device
connector
WRONG
